ALSTON CHASSIS AND SUBFRAME KITS

Filter Results by Vehicle
ALSTON CHASSIS AND SUBFRAME KITS
Description & Part #
Base

ALSTON LADDER BAR LOCATOR

Part # AL-181371

Bolt-On Track Locator. Use with ALSTON Ladder Bars, Features 5/8” clevis

FAR STRONGER than our standard Track Locator, this Locator has a unique “BOLT-ON” feature. A special threaded clevis, of our own design, replaces the nut on the bolt that attaches the ladder bar to the rear end and chassis. Left and right hand threaded heim joints allow you to make precise bar adjustments, without the need to remove the locator from the car. The extra smooth operation eliminates any bind from the system while keeping the rear end square in the chassis. Made from 7/8 O.D. X 36”, 4130 chrome moly tubing and heavy duty clevis.

UntitledWARNING: This product can expose you to chemicals including nickel and urethane, which are known to the State of California to cause cancer and birth defects or other reproductive harm.  For more information go to www.P65Warnings.ca.gov.

$161.00

ALSTON RACING DROPPED CROSS MEMBER

Part # AL-101711

2”x3”x.083 wall rectangle tube 58” long

In addition to adding extra strength to the chassis these cross members feature 3” drop center. The extra driveline clearance, either under or over, provides extra support in the event of driveline failure. The universal design features extra tubing to accommodate almost any kind of frame. Two mandrel bent styles are available, round 1 5/8” and 2”x 3” rectangle mild steel.

UntitledWARNING: This product can expose you to chemicals including nickel and urethane, which are known to the State of California to cause cancer and birth defects or other reproductive harm.  For more information go to www.P65Warnings.ca.gov.

$83.00

ALSTON RACING DROPPED CROSSMEMBER

Part # AL-101710

1 5/8”x.134 wall round tube 50” long

In addition to adding extra strength to the chassis these cross members feature 3” drop center. The extra driveline clearance, either under or over, provides extra support in the event of driveline failure. The universal design features extra tubing to accommodate almost any kind of frame. Two mandrel bent styles are available, round 1 5/8” and 2”x 3” rectangle mild steel.

UntitledWARNING: This product can expose you to chemicals including nickel and urethane, which are known to the State of California to cause cancer and birth defects or other reproductive harm.  For more information go to www.P65Warnings.ca.gov.

$61.00

ALSTON RACING PRO-LINK 4-LINK FRAME

Part # AL-102112

KIT INCLUDES:
Pair 2 X 3 Mandrel Bent Frame Rails
2 x 3 Dropped Cross Member
Pair 2 x 3 Sub Frame Connectors
1 5/8” Upper Coil Over Shock Cross Member
With Tabs & Hardware
1 5/8” Rear Cross Member

OPTIONS:
Wilwood Disc Brake Kit
Strange 35 spline Axles
Strange Center Section

Also Available in 1 5/8” Round Tube item 102111

UntitledWARNING: This product can expose you to chemicals including nickel and urethane, which are known to the State of California to cause cancer and birth defects or other reproductive harm.  For more information go to www.P65Warnings.ca.gov.

$426.00

ALSTON RACING TRACK LOCATORS- PRO LINK

Part # AL-181311

Bolt-On Track Locator. Use with Pro-Link,Features 5/8” bolts

FAR STRONGER than our standard Track Locator, this Locator has a unique “BOLT-ON” feature. A special threaded clevis, of our own design, replaces the nut on the bolt that attaches the ladder bar to the rear end and chassis. Left and right hand threaded heim joints allow you to make precise bar adjustments, without the need to remove the locator from the car. The extra smooth operation eliminates any bind from the system while keeping the rear end square in the chassis. Made from 7/8 O.D. X 36”, 4130 chrome moly tubing and heavy duty clevis.

UntitledWARNING: This product can expose you to chemicals including nickel and urethane, which are known to the State of California to cause cancer and birth defects or other reproductive harm.  For more information go to www.P65Warnings.ca.gov.

$161.00

ALSTON RACING TRACK LOCATORS- SPORTSMAN

Part # AL-181312

Bolt-On Track Locator. Use on any Kit or Sportsman 4-Link with 3/4” bolt

FAR STRONGER than our standard Track Locator, this Locator has a unique “BOLT-ON” feature. A special threaded clevis, of our own design, replaces the nut on the bolt that attaches the ladder bar to the rear end and chassis. Left and right hand threaded heim joints allow you to make precise bar adjustments, without the need to remove the locator from the car. The extra smooth operation eliminates any bind from the system while keeping the rear end square in the chassis. Made from 7/8 O.D. X 36”, 4130 chrome moly tubing and heavy duty clevis.

UntitledWARNING: This product can expose you to chemicals including nickel and urethane, which are known to the State of California to cause cancer and birth defects or other reproductive harm.  For more information go to www.P65Warnings.ca.gov.

$181.00

ALSTON RACING WISHBONE LOCATOR

Part # AL-181355

The Wishbone Rear Axle Housing Locator is designed to provide an alternative to the track locator for 4-Link suspensions. It is constructed of 4130 chrome moly tubing, includes hardware and all brackets necessary for installation

UntitledWARNING: This product can expose you to chemicals including nickel and urethane, which are known to the State of California to cause cancer and birth defects or other reproductive harm.  For more information go to www.P65Warnings.ca.gov.

$245.00

UNIVERSAL OR PRO-LINK LADDER BAR FRAME

Part # AL-102113

KIT INCLUDES:
1 5/8” Upper Coil Over Shock Crossmember
Pair 2 X 3 Mandrel Bent Frame Rails
2 x 3 Dropped Cross Member
2 x 3 Sub Frame Connectors

OPTIONS AVAILABLE:
Wilwood Disc Brake Kit
Strange 35 Spline Axles
Strange Center Section

Also Available in 1 5/8” Round Tube- Item #102114

UntitledWARNING: This product can expose you to chemicals including nickel and urethane, which are known to the State of California to cause cancer and birth defects or other reproductive harm.  For more information go to www.P65Warnings.ca.gov.

$426.00

UNIVERSAL OR PRO-LINK LADDER BAR FRAME

Part # AL-102113

KIT INCLUDES:

1 5/8” Upper Coil Over Shock Crossmember

Pair 2 X 3 Mandrel Bent Frame Rails

2 x 3 Dropped Cross Member

2 x 3 Sub Frame Connectors

OPTIONS AVAILABLE:

Wilwood Disc Brake Kit

Strange 35 Spline Axles Strange Center Section

Also Available in 1 5/8” Round Tube- Item #102114

UntitledWARNING: This product can expose you to chemicals including nickel and urethane, which are known to the State of California to cause cancer and birth defects or other reproductive harm.  For more information go to www.P65Warnings.ca.gov.

$426.00
